MSI MPG B850I Edge TI WiFi Motherboard
🌱 Environmental Impact
🌳 2.00 Trees Planted on This Purchase♻️ 200kg Offset
Each Tree Have Lifetime CO2 Removal Capacity of 100 Kg
✈️ Estimate Delivery:
53
People watching this product now!
17
Items sold in last 3 hours
- *Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
- *Supports DDR5 Memory, Dual Channel DDR5 8200+ MT/s (OC)
- *Ultra Performance: Direct 8+2+1 Power Design, Core Boost, Memory Boost, 10-layer PCB made by 2oz thickened copper and server-grade level material
₹23,249
₹3,546 GST Included in the Price
You can claim GST with B2B Billing Enter GST No at Checkout
In stock
Notice any issues?
Missing Product?
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
1-5 Working Days
-
Official Brand Warranty (Check with Manufacturer)
-
3 Days DOA Replacement
Description
MSI MPG B850I Edge TI WiFi Motherboard, ATX – Supports AMD Ryzen 9000/8000 / 7000 Processors, AM5-90A SPS VRM, DDR5 Memory Boost (8200+MT/s OC), PCIe 5.0 x16, M.2 Gen5, Wi-Fi 7, 5G LAN
Feature
- Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
- Supports DDR5 Memory, Dual Channel DDR5 8200+ MT/s (OC)
- Ultra Performance: Direct 8+2+1 Power Design, Core Boost, Memory Boost, 10-layer PCB made by 2oz thickened copper and server-grade level material
- Frozr Guard: Enlarged heatsink, MOSFET thermal pads rated for 7W/mk and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
- EZ DIY: EZ Antenna, EZ Conn-Design and EZ Front Panel Cable
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 M.2
- High-speed Connectivity: 5G LAN with Wi-Fi 7 Solution and USB 20Gbps- The latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
- Audio Boost 5: Reward your ears with studio grade sound quality for the most immersive gaming experience
Strong Performance, Sleek Design
MPG B850I EDGE TI WIFI
The MSI MPG B850I EDGE TI WIFI is a compact Mini-ITX motherboard built for gamers and PC builders who want top-tier performance in a small form factor. Powered by the AMD B850 chipset, it supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors, DDR5 memory, and high-speed PCIe 5.0. With full-speed Wi-Fi 7 support and a robust power solution, this motherboard delivers powerful performance without sacrificing size or style.
Supports AMD Ryzen 9000 / 8000 / 7000 Series Desktop Processors
The MPG B850I EDGE TI WIFI motherboard supports AMD Ryzen 9000 / 8000 / 7000 Series processors.
- Form Factor: ITX
- Socket Type: AM5
- Chipset: AMD B850
Ultra Power – Direct 8 phases power with 90A Smart Power Stage
With exclusive Core Boost technology and EZ OC Tuning functions, the MPG B850I EDGE TI WIFI is able to sustain heavy CPU power loads to support system-demanding game settings:
- Digital PWM IC
- 8-Phase direct CPU power (90A / SPS)
- 2 Phase SOC Power
- 1 Phase MISC Power
Frozr Design
- Frozr Guard: Extended Heatsink design, Heat-pipe, 7W/mK MOSFET thermal pads and M.2 Shield Frozr for improved thermal dissipation.
- Frozr Sync: Connect and synchronize cooling with strategically placed pin-headers – including CPU fan header (2A), Combo fan (3A, supports both pump fan and system fan) and system fans.
- Frozr Control: Manage speeds and temperature for all fans of your system in MSI Center with Cooling Wizard and Frozr AI Cooling.
2 x DDR5 Dual Channel (8200+ MT/s OC)*
- Memory Boost: A fully-isolated DDR circuit delivers pure data signals for optimal gaming and overclocking performance.
- High-Efficiency Mode: Enabling High-Efficiency-Mode in the MSI BIOS increases memory bandwidth and reduces latency. Four different modes allow users to find out the optimal configuration based on the quality of their memory modules.
- EXPO Profiles in the MSI BIOS are MSI OC LAB optimized and can be easily enabled with auto power settings for optimized memory speed and stability.
* 1DPC 1R Max. overclocking frequency 8200+ MT/s, supports AMD EXPO.
Fortified PCIe 5.0 x16 Slot
MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points to support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor also shields the point of contact from electromagnetic interference.
- 1 x PCIe 5.0/4.0/3.0 x16 slot (with Steel Armor*)
* MSI Surface Mount Technology (SMT) solder welding improves signal clarity.
Gen5 M.2 Connector
The MPG B850I EDGE TI WIFI motherboard features MSI’s M.2 slots:
- 1 x Gen5 x4 128Gbps slot (with M.2 Shield Frozr)
- 1 x Gen4 x4 64Gbps slot
EZ DIY
The DIY Friendly designs optimize the assemble process and experience.
- EZ Antenna: MSI’s latest Wi-Fi antenna not only boasts a beautiful appearance but also features a magnetic design, making it easier to adjust the antenna’s placement.
- EZ Conn-Design: The header which allows users to connect MSI EZ 120 fans (7 pin) or MSI MPG P-series liquid cooling (11 pin) with only one cable.
- EZ Front Panel Cable: Provides an easier way to connect the case front panel to the motherboard, allowing you to pre-connect the front panel cables outside the case.
High-speed Connectivity
- 5G LAN: A Realtek 5Gbps LAN controller delivers a premium network gaming experience.
- Wi-Fi 7: Features the full-speed Wi-Fi 7 solution (ultra-low latency, high-bandwidth) & Bluetooth 5.4 technology.
- USB 20Gbps Front Type-C: Connect to devices and transfer files at high bandwidth rates.
Additional information
Specification
Specification
| Feature | Specification |
| Chipset | AMD B850 |
| CPU | Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors, Socket AM5 |
| Memory | 2x DDR5 UDIMM, Maximum Memory Capacity 128GB, Memory Support DDR5 10000 – 5600 (OC) MT/s / 5600 – 4800 (JEDEC) MT/s, Ryzen™ 9000 Series Processors max. overclocking frequency:, • 1DPC 1R Max speed up to 8200+ MT/s, • 1DPC 2R Max speed up to 8000+ MT/s, Supports AMD POR Speed and JEDEC Speed, Supports Memory Overclocking and AMD EXPOTM, Supports Dual-Channel mode, Supports Non-ECC, Un-buffered memory, Supports CUDIMM, Clock Driver bypass mode only*, * CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility., • The DIMM slots on this motherboard1 only have double-sided latches., • Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product’s Support 2page or visit https://www.msi.com/support/. |
| Onboard Graphics | 1x HDMI™, Support HDMITM 2.1 with FRL port, supporting a maximum resolution of 8K 60Hz*, *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| Slot | 1x PCI-E x16 slot, PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), PCI_E1 slot, • Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors), • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors), • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor) |
| Audio | Realtek® ALC4080 Codec, 7.1-Channel USB High-Performance Audio, Supports up to 32-Bit/384 kHz playback on front panel, Supports S/PDIF output |
| Storage | 2x M.2, M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280 devices, M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280 devices, 2x SATA 6G, M.2_1 slot, • Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors), • Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors), M.2_2 slot, • Supports up to PCIe 4.0 x4, • Supports 2280 storage devices |
| RAID | • Supports RAID 0, and RAID 1 for SATA storage devices, • Supports RAID 0, and RAID 1 for M.2 NVMe storage devices |
| USB | 2x USB 2.0 (Front), 2x USB 5Gbps Type A (Rear), 2x USB 5Gbps Type A (Front), 3x USB 10Gbps Type A (Rear), 1x USB 10Gbps Type C (Front), 1x USB 20Gbps Type C (Rear) |
| LAN | 1x Realtek® 8126 5G LAN |
| Internal IO | 1x Power Connector(ATX_PWR), 1x Power Connector(CPU_PWR), 1x CPU Fan, 1x Combo Fan (Pump_Sys Fan), 1x System Fan, 1x EZ Conn-header (JAF_2), 2x Front Panel (JFP), 1x Chassis Intrusion (JCI), 1x Front Audio (JAUD), 1x Addressable V2 RGB LED connector (JARGB_V2), 1x TPM pin header(Support TPM 2.0), 2x USB 2.0 ports, 2x USB 5Gbps Type A ports, 1x USB 10Gbps Type C ports |
| WIRELESS LAN & BLUETOOTH | Wi-Fi 7, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps, Supports 802.11 a/ b/ g/ n/ ac/ ax/ be, Supports Bluetooth® 5.4**, MLO, 4KQAM, * 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2., ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.3 |
| LED FEATURE4 | 4x EZ Debug LED, 51x EZ Memory Detection LED |
| OPERATING SYSTEM | Support for Windows® 11 64-bit |
| PCB Info | Mini-ITX, 170mmx170mm |
| warranty period | 3 year |
| Note | Features, price, and specifications are subject to change without notice. Images are for representation only. |
